Ranging from 4000 – 7000 lbs. in capacity, our EcoMaxx FD20-35 models utilize the latest technology and advanced engineering to create quiet, low emission diesel powered lift trucks. Our EcoMaxx FD20-35 models are equipped with EPA-approved Tier IV Kohler diesel engines that reduce fuel consumption while reducing harmful carbon emissions. Stock features such as a rubber mounted trans-axle to reduce noise and vibration, ergonomic rear-mounted horn/handle, deluxe suspension seat, Cascade sideshifts and 4th valve and IHR, the EcoMaxx line is great for your bottom line without cutting corners in quality.

Notable features include:

  • Trucker, duplex and triplex masts available with lift heights from 78.7″ – 270″
  • Pneumatic solid or pneumatic air tire options
  • Optional dual load wheels, extra wide carriage and load backrest
  • Ask us about more customization options


Capacity 4,000 – 7,000 lbs.
Lift Height 78.7″ – 270″
Turning Radius  78.0″ – 96.3″
Travel Speed  9.0 – 11.8mph (laden)
Lift Speed 16.1 – 19.3 in/s (laden)
Gradeability  20%


Diesel Engine

Engine Kohler KDI1903TCR
Type Tier IV Turbo Charged
Displacement  1861
Horsepower  56
Torque  165.9ft-lb


Transmission Powershift Automatic
Service Brake Hydraulic
Parking Brake  Hand
